Ultrasonic Intelligent Automatic Scale, body weight scale

Introduction

The height and weight integrated machine, also known as the ultrasonic intelligent automatic scale, combines advanced ultrasonic measurement technology and intelligent control algorithms. It is a precision health detection device that provides users with accurate and convenient height and weight measurement services. The ultrasonic intelligent automatic scale is applicable to scenarios such as hospitals, medical institutions, communities, schools, health check – up centers, elderly care institutions, beauty and fitness venues, shopping malls, pharmacies, pedestrian streets, and families.

Features

• Precise Measurement: High – precision millimeter – wave sensors are used for height measurement, with an accuracy of up to ±0.5cm. The weight measurement relies on the precision resistance strain gauge sensor on the scale platform, with an accuracy of ±0.1kg.
• Intelligent and Convenient: Equipped with a 5.0 – inch high – definition LCD screen, it broadcasts measurement results with simulated human voice, and the switch is controllable. The ultrasonic intelligent automatic scale comes with a thermal printer, making it convenient to obtain a paper report.
• Data Transmission: Supports data transmission via RS232 serial port and Bluetooth, and is compatible with various systems such as HIS/LIS systems, computers, APPs, and the national public health system, facilitating data sharing and management.
• Portable Design: The ultrasonic intelligent automatic scale adopts a retractable design. After folding, it is 1.2 meters high, saving space. It comes with rollers, which is convenient for transportation and easy to move to different locations.

Parameters

• Name: Ultrasonic Intelligent Automatic Scale
• Screen Size: 5.0 – inch high – definition LCD screen
• Height Measurement Range: 20 – 210cm, with a division value of 0.5cm or 0.1cm (adjustable)
• Weight Measurement Range: 2 – 500kg, with a division value of 0.1kg or 0.01kg (adjustable)
• Folding and Portability: After folding, it is 1.2 meters high and can be easily placed in a medical examination vehicle. It has rollers.
• Weight Measurement Method: Precision resistance strain gauge sensor
• Height Measurement Method: High – precision millimeter – wave sensor
• Data Communication: RS232
• Measurement Speed: 480 times per hour
• System Compatibility: HIS/LIS systems, computers, APPs, electronic medical records, national public health systems, etc.
• Power Supply: AC100V – 240V (50Hz/60Hz), with a power consumption of ≤10W, approximately 1 kWh in 100 hours
• Working Environment: Temperature – 10℃ to + 40℃
• Overall Dimensions: 500 * 350 * 2350 (length * width * height, mm)
• Equipment Weight: Net weight: 15KG, with packaging: 20KG
